Tamtorque sign fixing clamps have been designed for clamping signs of all types to round, square, hexagon or any unusual shaped post, giving a quick and reliable fix every time. They are available in seven diameters covering post sizes from 55mm to 340mm diameter without the need to cut the band to size. They do not therefore have sharp edges which can snag or cut and, unlike other banding systems, can be easily re-used or readjusted.
Tamtorque sign fixing clamps are manufactured from high strength stainless steel and have a hardened tamper resistant screw with a unique recessed seven-sided socket. This means that they can only be tightened or released with a special Tamtorque screw bit.
An auto locking safety buckle ensures the free end of the band is both safe and tidy. The unique safety buckle was developed especially for TAMTORQUE and is covered by patents in many countries. European Patent No 0891508. US Patent No 6205624. Other patents are pending.
Typical applications for Tamtorque sign fixing clamps include securing waste bins and litter bins, street lamp and signal control box security and clamping road, public, industrial and advertising signs.
Slide the buckle onto the band in the direction of the arrow and push around to the housing.
Thread the band through the slots in the sign and around post.
Engage the band into the screw housing and screw band through by approximately 50mm.
Locate the tongue of the buckle in the 4th slot of the band. Screw the band through using a hand or power tool.
Hold down any excess band just before the buckle is clamped finally tighten with the Tamtorque T-bar driver or ratchet spanner.
Push and remaining excess band through the buckle for a safe tidy job. Tamtorque can be released and repositioned if required.
Tamtorque T-Bar driver/rachet spanner also available in our tools section.
Click here to download this page in pdf format
JCS part no’s:
TTK(70)P, TTK(100)P, ttk(130)P, TTK(160)P, TTK(190)P, TTK(250)P, TTK(340)P,
Stainless steel 304 grade
|Stock Code||Size||Diameter (mm)||Diameter (ins.)|
|TAM070||70||55-70||2 1/8 – 2 3/4|
|TAM100||100||70-100||2 3/4 – 4|
|TAM130||130||100-130||4 – 5 1/8|
|TAM160||160||130-160||5 1/8 – 6 1/4|
|TAM190||190||130-190||5 1/8 – 7 1/2|
|TAM250||250||190-250||7 1/2 – 9 7/8|
|TAM340||340||250-340||9 7/8 – 13 3/8|
