Tridon 845 Flex Gear Clamps Full SS

£0.00

Heavy duty clamp with a belleville spring to maintain constant tension.

Full stainless steel.

Enquire Now

Description

Tridon 845

Flex-Gear 45 all stainless steel heavy duty clamps use a Belleville spring design to eliminate “cold flow” leakage in heavy duty applications and adjust with the hose and fitting to maintain constant tension on the connection, eliminating leak paths.

Flex-Gear clamps are an excellent choice for fluctuating and extreme temperature applications and thermal compensation.

Material Specifications

Screw: 3/8″ Hex Head, 410 Stainless

Housing: 300 Stainless

Spring: 300 Stainless

Band: 5/8″, 300 Stainless

Installation Torque: 75 in-lbs (8.5 Nm)

FLEX-GEAR HDCLAMPING RANGE
SAE SizesIdeal Part No.Tridon Part No.English (in.)Metric (mm)Fits Hose I.D.
Min. Dia.Max. Dia.Min. Dia.Max. Dia.Min. Dia.Max. Dia.
4145
175411754517511 3/425457/81 1/8
21241200452001 1/42 1/8325411 1/2
26241250452501 3/42 5/845671 1/22
31241300453002 1/43 1/8577922 1/2
36241350453502 3/43 5/870922 1/23
41241400454003 1/44 1/88310533 1/2
46241450454503 3/44 5/8951173 1/24
51241500455004 1/45 1/810813044 1/2
56241550455504 3/45 5/81211434 1/25
61241600456005 1/46 1/813315555 1/2
66241650456505 3/46 5/81461685 1/26
71241700457006 1/47 1/815918166 1/2
76241750457506 3/47 5/81721936 1/27
81241800458007 1/48 1/818420677 1/2
86241850458507 3/48 5/81972197 1/28
91241900459008 1/49 1/821023288 1/2
FLEX-GEARCLAMPING RANGE
SAE SizesIdeal Part No.Tridon Part No.English (in.)Metric (mm)Fits Hose I.D.
Min. Dia.Max. Dia.Min. Dia.Max. Dia.Min. Dia.Max. Dia.
4347
1043010470109/161 1/1614273/85/8
1243012470125/81 1/416323/83/4
16430164701613/161 1/221383/47/8
20430204702013/161 3/420443/41 1/8
2443024470241 1/16227517/81 3/8
2843028470281 5/162 1/433571 1/41 5/8
3243032470321 9/162 1/240631 1/21 7/8
3643036470361 13/162 3/446701 3/4 2
4043040470402 1/163527622 1/4
4443044470442 5/163 1/459822 1/42 1/2
4843048470482 9/163 1/265892 1/23
